GE -VMIVME-1182  Digital Input Board
❤ Add to collection

GE -VMIVME-1182 Digital Input Board

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

GE -VMIVME-1182  Digital Input Board

28756.00
¥27740.00
Weight:4.000KG
Quantity:
(Inventory: 15)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

GE -VMIVME-1182  Digital Input Board


GE -VMIVME-1182  Digital Input Board

Features:

• 64 optically isolated inputs

• Multifunctions available per channel

− Change-of-State (COS)

− Sequence of Events (SOEs)

− Pulse accumulation

− Programmable debounce times

− Time tagging

• 5 to 250VDC or 4 to 240VAC

• 1,500VDC or 1,100VRMS channel-to-channel and  channel-to-VME isolation

• Pulse accumulation (0 to 65,535 pulses)

• SOEs monitoring on channel-by-channel basis

• Debounce times, software controlled on  channel-by-channel basis

• 1.0ms measurement interval

• COS functions, software controlled on a  channel-by-channel basis

• COS selections: disabled, rising edge (low-to-high  transition), falling edge (high-to-low transition) or any  edge

• Short or standard, supervisory, nonprivileged or either  access

• Interrupt level is user selected

• UIOC® compatible

• Complies with ANSI/IEEE STD C37.90.1-1989 surge  protection when used with companion suppression panel  (for example, VMIVME-3459)

Applications:

• Data acquisition systems

• Nuclear power plant monitoring

• Control systems

Change-Of-State (COS) Timing:

The VMIVME-1182 latches the  input signals every millisecond. After a programmable debouce  time, if a valid COS is detected, it is time tagged by the  millisecond timer and stored for processing. The debounce time  can be from 1.25ms to 1.024s. Therefore, the minimum pulse  time that can be reliably detected is 2ms.

If the VMIVME-1182 is programmed to detect COS on both rising  and falling edges, the minimum time in each state is 2ms. Thus,  4ms is the minimum period of a continuous input signal.

Each input channel is independent and is processed separately,  so activity on one channel has no effect on other channels. A  COS on one channel can be detected and stored while the  debouncer is timing on another channel. Since all inputs are  latched simultaneously every millisecond and they are  processed separately, there can be a minimum of 1ms between  events that occur on different channels.

Change-Of-State Detection:

State change detection can be  programmed for rising edge (low-to-high transition), falling edge  (high-to-low transition), or both rising and falling edges. In  addition, COS detection can generate an interrupt or be  disabled.

Time Tagging:

Each Change-of-State event can be time tagged  with a timer value of 0 to 65s and is initialized or preset by  writing to the time tag register.

The timer value is updated every millisecond. When the timer  value has reached its maximum value, it rolls over to 0 and  notifies the host of a time tag rollover via a bit in the Control  Register, or if desired, an interrupt may be issued.

Introduction:

The VMIVME-1182 provides 64 digital inputs with  which COS can be detected, time tagged and counted. An  onboard buffer can be programmed to store the COS  information with a time-tag such that SOEs can be analyzed. A  pulse accumulator is provided to count the COSs. The  VMIVME-1182 can also be programmed to issue an interrupt  when a COS is detected. All COS detection is on a per-channel  basis effectively creating 64 pulse accumulators.

The SOE memory is allocated into two buffers. The system host  can be processing one buffer while the other buffer is being  loaded with new event data.

Environmental Specifications

Dimensions:Standard VME do eight board

Height: 9.2 in. (233.4mm)

Depth: 6.3 in. (160mm)

Thickness: 0.8 in. (20.3mm)

Power Requirements:2.0A (typ dissipated in pull-up resistors

Temperature:

Operating: 0 to +65° C

Storage: -25 to +85° C

Altitude:Operating: 0 –10,000 ft (3,048m)

Humidity:Operating: relative humidity 20%to 80%, noncondensing
