GE IC200MDL240 AC Input Module for Industrial Control

GE IC200MDL240  AC Input Module for Industrial Control

Input Voltage Range:85 to 264 Vac Operating Temperature:-40 to 70 "C Communication Interface:RS-485 Relay Outputs:8 channels Input Protection:2 kV AC Operating Current:Max 5 mA per channel The GE IC200MDL240 AC Input Module is engineered for compatibility with a wide range of industrial control systems, ensuring seamless integration with existing infrastructure. Each of its 16 channels supports high-precision signal acquisition, enabling accurate data collection from various sensors and equipment.

 With an operating voltage range of 85-264VAC, this module is designed to withstand challenging industrial environments, making it suitable for applications in diverse industries including manufacturing, energy, and automation. Featuring a Modbus RTU communication interface, the module facilitates easy setup and configuration, streamlining the process of data exchange within complex systems. The robust design ensures reliable operation across a broad temperature range (-10"C to +60"C) and humidity conditions (5% to 95% non-condensing), guaranteeing consistent performance under varying environmental conditions.

 Manufactured with high-quality materials and advanced technology, the GE IC200MDL240 is a testament to GE  commitment to delivering cutting-edge solutions for industrial automation. The GE IC200MDL240 is an essential component for industrial control systems, designed for high reliability and precision in handling AC input signals. It seamlessly integrates into GE  Mark VI system, providing unparalleled performance for critical operations.

Features

▪ Contains 10 Mbytes of battery-backed user memory and 10 Mbytes of non-volatile flash user  memory.

▪ Provides access to bulk memory via reference table %W.

▪ Configurable data and program memory.

▪ Programming in Ladder Diagram, C, Structured Text, and Function Block Diagram.

▪ Supports auto-located Symbolic Variables that can use any amount of user memory.

▪ Reference table sizes include 32Kbits for discrete %I and %Q and up to 32K words each for  analog %AI and %AQ.

▪ Supports Series 90-70 discrete and analog I/O, communications, and other modules. For a  list of modules supported, refer to the PACSystems RX7i Installation Manual, GFK-2223.

▪ Supports all VME modules supported by Series 90-70.

▪ Supports RX7i data monitoring over the web. Allows a combined total of up to 16 web server  and FTP connections.

▪ Supports up to 512 program blocks. Maximum size for a block is 128KB.

▪ Test Edit mode allows you to easily test modifications to a running program.

▪ Bit-in-word referencing.

▪ Battery-backed calendar clock.

▪ In-system upgradeable firmware.

▪ Three isolated serial ports: an RS-485 serial port, an RS-232 serial port, and an RS-232  Ethernet station manager serial port.

▪ The embedded Ethernet interface provides:

- Data exchange using Ethernet Global Data (EGD)

- TCP/IP communication services using SRTP

- Support for SRTP Channels, Modbus/TCP Server, and Modbus/TCP Client

- Full programming and configuration services

- Comprehensive station management and diagnostic tools

- Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network  switch providing auto-negotiated network speed, duplex mode, and crossover detection.

- User-configurable Redundant IP address

- Time synchronization to SNTP time server on Ethernet network (when used with  Release 5.00 or later CPU module).
