GE IC755CSW07CDA Operator Interface for the Industrial Internet
❤ Add to collection

GE IC755CSW07CDA Operator Interface for the Industrial Internet

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

Streamline your system and simplify

development and maintenance with

one powerful device for both your

operator interface (OI) and control

requirements. The QuickPanel+,

OI for the Industrial Internet, is a

multi-functional device that delivers

actionable data and insight—smarter,

faster and easier than ever before.

￥16665.00
￥13778.00
Weight：3.500KG
Quantity：
(Inventory: 33)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

Streamline your system and simplify

development and maintenance with

one powerful device for both your

operator interface (OI) and control

requirements. The QuickPanel+,

OI for the Industrial Internet, is a

multi-functional device that delivers

actionable data and insight—smarter,

faster and easier than ever before.

GE IC755CSW07CDA Operator Interface for the  Industrial Internet
QuickPanel+

integrates process control,
view, and an option to run embedded
data historian to improve real-time
control and simplify integration into
plant-wide systems. The QuickPanel+
takes machine interfaces into the
Industrial Internet age for new levels
of productivity, insight, and user
experience.
To succeed in an outcome-driven world,
businesses must operate faster and
leaner and be increasingly connected.
At GE's Automation & Controls, we
understand today’s connected business
environment, and are committed to
simplifying it. That’s why we’ve designed
an automation architecture that helps
you design better machines and plants,
operate them smarter, and redefine the

interaction with your equipment.

High Performance
With faster processing speeds and more
memory, QuickPanel+
delivers highperformance control, visualization, and
data historian capabilities to maximize
productivity and cost efficiency, even in
third-party environments.
QuickPanel+
incorporates the latest display
and multi-touch technology to enhance
the user experience. The capacitive,
multi- touch screen is built to last in an
industrial environment, yet is as sensitive
as the latest smartphone or tablet. The
wide screen pro- vides vivid, clear images
and more complete process visualization.
Double-tap or pinch to view your interface
at up to 400% and tap twice to return to
original size. Swipe to navi- gate between
interactive schematics.
Multi-functional Capability
QuickPanel+
provides core capabilities that
help users operate in today’s connected
world. It’s an all-in-one OI: an OI/HMI, a
PLC/ process controller, machine gateway,
and a data historian. This combination puts
more data at your fingertips, providing
instant insight and control while reducing
inventory and TCO. Remote programming
technology makes it easy to access user
accounts through a single access point.
And, a single object-based programming
environment means implementation is fast
and easy.
Full-Function Browser &
Multimedia Access
QuickPanel+
offers a fully-functional web
browser and multimedia support with
the Windows EC7 operating system. This
results in a new level of versatility for an
OI. Users can quickly and easily access the
Internet or their intranet to view training
videos, compile reports or access other
critical information.
Interoperability & Flexibility
The plug-and-play interoperability of the
QuickPanel+
adds to its ease of use and
implementation. Using serial and Ethernet
connectivity, it can be used with controllers
and I/O from multiple vendors for swift
and smooth implementation. Enjoy the
functionality of a PC—such as remote
connectivity through VNC, web browser,
built-in peer networking, SNMP, and FTP and
HTTP servers— without the IT headaches.
QuickPanel+
supports 5 IEC 61131-3
programming languages: Ladder Diagram
(LD), Sequential Function Chart (SFC),
Structured Text (ST), Instruction List (IL), and
Function Block Diagram (FBD). The operator
can select multi-language support when the
system is online. Configuration is easy — a
common database reduces development
time by eliminating the need to re-enter
tag names, and an extensive library of preconfigured animation objects is provided.


Specifications
Processor Node
• Freescale i.MX535 1GHz based on ARM Cortex A8
• 2D/3D Graphics Processing Unit
• 32KB Level 1 Instruction/Data Caches
• 256KB Level 2 Unified Instruction and Data Cache
• NEON SIMD Media Accelerator
• Vector Floating Point Coprocessor
Memory
• 512MB DDR2 SDRAM
• 256MB SLC NAND Flash
• 512KB Battery Backed SRAM
Display
• 7" Widescreen TFT LCD
• 800 x 480 Resolution
• Projected Capacitive Display
• Multi-touch (two-point)
Ethernet Port
• 1x 10/100BaseT (RJ-45)
Serial I/O
• 1x RS-232 COM Port (5-Pin Connector)
USB
• 2x USB 2.0 (Type-A)
• 1x USB 2.0 (Mini Type-B)
Storage
• 1x SD/SDHC Card Slot
Audio
• x1 Mic In (mono) (3.5mm Jack)
• x1 Line Out (stereo) (3.5mm Jack)
Status Indicators
• Tri-color LED (Amber/Green/Red)
• On-board Buzzer
Operating System
• Microsoft® Windows® Embedded Compact 7
Power Requirements
• +24VDC ±20% (3-Pin Connector)
• Max power Consumption: 15W
Physical Specification
• External Dimensions: 192(W) x 137(H) x 36(D) mm
• Weight: 800g
Mounting Option
• Panel Cutout Dimensions: 183.5(W) x 128.5(H) mm
• Panel Mount Brackets Included
• Mounting Gasket
• VESA 75
Environmental
• Cooling Methodology: Natural Convection
• Operating Temp: 0°C to +55°C
• Storage Temp: -10°C to +60°C
• Humidity: 85% RH (non-condensing) @ 30°C
• ATEX Certification – IC755CSW07CDACA
Compliance
• UL Listed US/CAN Hazardous locations:
Class 1 Division 2, Class 2 Division 2, Class 3 Division 1
• UL TYPE 4X
• CE (EN 60950-1, EN 61000-6-4, 61000-6-2)
• FCC Part15 Class A
• IP65F (JEM 1030)
• DNV Marine Certification – Approved on
IC755CSW07CDACA
• RoHS
Ordering Information
Operator Interfaces
IC755CSW07CDA QuickPanel+
View & Control, 7" Color TFT Widescreen with Multi-touch Projected
Capacitive Screen, GE Monogram Bezel, 24 VDC Powered
IC755CBW07CDA QuickPanel+
View & Control, 7" Color TFT Widescreen with Multi-touch Projected
Capacitive Screen, Blank Bezel, 24 VDC Powered
IC755CSW07CDACA QuickPanel+
View & Control, 7" Color TFT Widescreen with Multi-touch Projected
Capacitive Screen, GE Monogram Bezel, 24 VDC Powered, Conformal Coated
Accessories
IC755ACC07GAS QuickPanel+
7"/6" Replacement Gasket
IC755ACC07MNT QuickPanel+
7"/6" Accessory Kit - Replacement Mounting Clips, Power &
Serial Port Connectors
IC755ACC07PRO QuickPanel+
7" Replacement Screen Protectors, Package of 3
IC755ACCBATT QuickPanel+
Replacement Battery Pack
IC755ACC07ADP QuickPanel+
Panel Adapter Kit - 8" QP View/Control to 7" QuickPanel+
