Series:Mark VI IS200 Manufacturer:General Electric Functional Acronym/Abbreviation:ICBD Product Type:Printed Circuit Board Number of Connectors:15 Dimensions:Specific dimensions listed in factory-manual Performance Specifications:Details regarding power handling, signal integrity, and operational efficiency The IS200ICBDH1BAA is part of the renowned General Electric Mark VI IS200 series, known for its robustness and compatibility across various industrial environments.

 This printed circuit board boasts a total of 10 diodes, 61 capacitors, 95 resistors, 3 transformers, 15 integrated circuits, an inductor coil, and a fuse, ensuring optimal performance in control systems. Equipped with an RS-232 9-pin port and four Ethernet jacks (labeled J11A, J11B, J12A, and J12B), the IS200ICBDH1BAA facilitates efficient data communication and connectivity, making it indispensable for modern industrial setups. Notably, the inclusion of a circular 8-pin female port offers additional flexibility in system configurations, enhancing the adaptability of this PCB in diverse applications.

 Designed with meticulous attention to detail, this General Electric product is crafted using high-quality materials for durability and longevity. Its compatibility with VME racks ensures seamless integration into existing infrastructure, streamlining system management and maintenance. Backed by the expertise and reliability of General Electric, the IS200ICBDH1BAA is an essential upgrade or replacement choice for industrial control systems, promising enhanced efficiency, safety, and operational reliability. Engineered for precision and reliability, the GE IS200ICBDH1BAA is a pivotal component in the Mark VI IS200 series, designed to enhance operational efficiency and system stability.
