Series:Mark VI IS200 Manufacturer:General Electric Functional Acronym/Abbreviation:ICBD Product Type:Printed Circuit Board Number of Connectors:15 Dimensions:Specific dimensions listed in factory-manual Performance Specifications:Details regarding power handling, signal integrity, and operational efficiency The IS200ICBDH1BAA is part of the renowned General Electric Mark VI IS200 series, known for its robustness and compatibility across various industrial environments.

 This printed circuit board boasts a total of 10 diodes, 61 capacitors, 95 resistors, 3 transformers, 15 integrated circuits, an inductor coil, and a fuse, ensuring optimal performance in control systems. Equipped with an RS-232 9-pin port and four Ethernet jacks (labeled J11A, J11B, J12A, and J12B), the IS200ICBDH1BAA facilitates efficient data communication and connectivity, making it indispensable for modern industrial setups. Notably, the inclusion of a circular 8-pin female port offers additional flexibility in system configurations, enhancing the adaptability of this PCB in diverse applications.

 Designed with meticulous attention to detail, this General Electric product is crafted using high-quality materials for durability and longevity. Its compatibility with VME racks ensures seamless integration into existing infrastructure, streamlining system management and maintenance. Backed by the expertise and reliability of General Electric, the IS200ICBDH1BAA is an essential upgrade or replacement choice for industrial control systems, promising enhanced efficiency, safety, and operational reliability. Engineered for precision and reliability, the GE IS200ICBDH1BAA is a pivotal component in the Mark VI IS200 series, designed to enhance operational efficiency and system stability.

Features

 Single-Slot Module

 SNP/SNP-X Protocol (master, slave)

 CCM Protocol (master, slave, peer)

 RTU Modbus Protocol (slave only)

 Supports connection to MS-DOS or Windows

 programming and configuration software package (monitor only)

 12 Mhz, 80C186 Microprocessor

 Two RS-422/RS-485 or RS-232 Serial Ports

 CCM, RTU and SNP/SNP-X Available on Either or Both Ports

 Simultaneous Communications on Both Ports (up to 9.6 Kbps, or 19.2 Kbps individually)

 High Performance Access to PLC Memory

 Three Status LEDs

 Reset pushbutton

 Soft Switch Configuration (no switches or jumpers)

 No Battery Required

Ease of Use

• Simple and powerful instruction set

• One-axis or two-axis motion programs with synchronized block start

• Program support for a short motion program (called Program Zero) which can be created in the MS-DOS programming software configuration function

• Nonvolatile (flash) storage for 10 programs and 40 subroutines

• User scaling of programming units (in Standard mode only)

• Generic programming using command parameters as operands for Acceleration, Velocity, Move and Dwell commands

• Configured with MS-DOS configuration software
