GE IS220PSCAH1A IO Pack for Serial Communications, Precision and Reliability in Industrial Control
Product Type:IO Pack Serial Communications:Yes Module Weight:0.38 kg Operating Voltage:12-24 VDC Communication Protocol:RS-485, Modbus Environmental Rating:IP20 Dimensions (WxHxD):100 x 20 x 120 mm Certification:CE, UL The GE IS220PSCAH1A is engineered for optimal performance in demanding industrial environments. It ensures reliable data transmission through its robust RS-232/RS-485 communication protocols, making it a critical component in complex automation setups. Crafted from high-grade materials, this IO Pack boasts a durable design capable of withstanding extreme temperatures and harsh conditions, ensuring long-lasting operation without maintenance interruptions.
With its compact size and efficient power consumption, the IS220PSCAH1A optimizes space usage and energy efficiency, making it an ideal choice for modern industrial facilities focused on sustainability and cost-effectiveness. This IO Pack seamlessly integrates with a variety of control systems, thanks to its versatile compatibility with multiple industrial standards. It supports seamless data exchange, enhancing productivity and efficiency across different sectors. Designed with user-friendliness in mind, the IS220PSCAH1A features intuitive setup procedures and straightforward diagnostics, allowing operators to quickly identify and resolve issues, minimizing downtime and maximizing operational efficiency. The GE IS220PSCAH1A is a versatile IO Pack designed for seamless serial communication, ideal for industrial automation and control systems where precise data exchange is critical.
Compatibility
ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.
ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.
ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).
ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.
ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.
Module features include:
ƒ Support for all standard data rates (125K, 250K, 500K)
ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave
ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master
ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS
ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging
ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device
ƒ Support for configuration of the global scan rate
ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis
ƒ Support for PLC-application initiated explicit messaging via a COMMREQ
ƒ Master can be configured to operate as a slave simultaneously with master operation
ƒ Configurable fault behavior on loss of communication
ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)
ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)
ƒ Firmware update via service port on module
