ABB 086339-001 stepper linear control motherboard
❤ Add to collection

ABB 086339-001 stepper linear control motherboard

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

Zur Verwendung in komplexen leittechnischen

Anwendungen sind alle wesentlichen Funktio nen der Station redundant konfigurierbar, so

auch die Datenverarbeitung, die Stromversor gung, die Schnittstellen zum Advant Fieldbus

100 und die E/A-Buserweiterungen. Das Um schalten auf andere Geräte, sogar auf andere

Zentraleinheiten, verläuft absolut stoßfrei und

transparent.

15000.00
¥15000.00
Weight:3.330KG
Quantity:
(Inventory: 15)
Consultation
Accessories
  • ABB-AC31-40-Adva
    Original :¥16354.00
    With a price :¥16354
    Quantity
  • ABB-07KR51-Centr
    Original :¥11222.00
    With a price :¥11222
    Quantity
  •
    Original :¥
    0.00

      With the total price :¥
    0.00
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

Zur Verwendung in komplexen leittechnischen

Anwendungen sind alle wesentlichen Funktio nen der Station redundant konfigurierbar, so

auch die Datenverarbeitung, die Stromversor gung, die Schnittstellen zum Advant Fieldbus

100 und die E/A-Buserweiterungen. Das Um schalten auf andere Geräte, sogar auf andere

Zentraleinheiten, verläuft absolut stoßfrei und

transparent.




ABB 086339-001 stepper linear control motherboard

und die Zuverlässigkeit des Systems
Zur Verwendung in komplexen leittechnischen
Anwendungen sind alle wesentlichen Funktionen der Station redundant konfigurierbar, so
auch die Datenverarbeitung, die Stromversorgung, die Schnittstellen zum Advant Fieldbus
100 und die E/A-Buserweiterungen. Das Umschalten auf andere Geräte, sogar auf andere
Zentraleinheiten, verläuft absolut stoßfrei und
transparent.
Graphische Anwendungsentwicklung
Der Advant Controller 160 wird mit dem
Funktionsplaneditor Function Chart Builder in
AMPL konfiguriert. AMPL ist die einheitliche
Konfigurations- und Programmiersprache für
Graphikanwendungen, die im gesamten Advant
OCS-Prozeßleitsystem in Verbindung mit der
Master-Software verwendet wird und logische
Verknüpfungen, arithmetische Funktionen und
kontinuierliche Regelungsaufgaben gleicherma-

ßen gut handhaben kann. Anwendungsprogramme werden Seite für Seite graphisch entwickelt,
indem die entsprechenden Funktionsbausteine ausgewählt und intern sowie mit

dem Prozeß verbunden werden.
Die Anwendungsprogramme sehen auf Papier
genauso aus wie am Bildschirm, was besonders
bei der Fehlerbeseitigung von Vorteil sein
kann: der Ausdruck gibt den Überblick, der
Bildschirm liefert die Details. Darüber hinaus
können Signalwerte während des Betriebs
aktualisiert und konfigurierte Signale bis zu
ihrer Quelle zurückverfolgt werden.
Optimale Prozessverbindungen
Zur Herstellung digitaler und analoger Ein- und
Ausgänge können an den Advant Controller
160 verschiedene E/A-Module der S600-Serie
angebunden werden. Der E/A-Bereich ist
sowohl für Wechsel- als auch für Gleichstrom
ausgelegt und eignet sich für preisgünstige
Module mit hoher Signaldichte genauso gut
wird für Hochleistungsmodule mit kV-Isolierung. Verfügbar ist auch ein intelligentes
Impulszählermodul zur genauen Längenmessung und Positionierung, das Impulsfrequenzen von bis zu 100 kHz verarbeiten
kann. Außerdem kann ein Drehzahl-Eingabemodul mit integrierter Abschaltlogik, das zur
Steuerung von Turbinen und anderen Umlaufmaschinen eingesetzt wird, an das System
angeschlossen werden.
Alle S600 E/A-Module sind in einem Blechgehäuse (Schutzart IP20) gekapselt, um Schutz
vor elektromagnetischen Störeinflüssen in der
Etage und vor mechanischen Beschädigungen
von außen zu bieten. Die Feldkabel sind über
Klemmen mit einer Steckkontaktleiste verbunden, die auf die Modulvorderseite aufgesteckt
wird - eine platzsparende und saubere Lösung.
Verteilte Ein- Ausgabe Geräte der Serie S800 E/
A können an den Advant Fieldbus 100 angekoppelt werden. Sie können bis zu 32 solcher
Ein- Ausgabegeräte installieren.


Alternative Stromversorgung
Direkt (Eingang nicht potentialgetrennt) 19,2-30 V DC
DC (Eingang potentialgetrennt) 110-125/220-250 V DC
AC (Eingang potentialgetr.)110/120/220/240 V, 47-450 Hz
Grundlegende Leistungsmerkmale
Zentraleinheit PM 640 und PM 644: (Unterstützt SC 610)
Taktfrequenz: 33 MHz
Programmspeicher, Flash-PROM 3,0 MB
Zentraleinheit PM 645A: (redundante Verarbeitung)
Taktfrequenz: 33 MHz
Programmspeicher, Flash-PROM 3.5 MB
PROFIBUS-DP Interface (PM644) max. 125 Slaves
Bitrate max. 12 MBit/sec.
Grundlegende Kommunikationsanschlüsse
PM 640:
RS 232C für Advant Engineering-Station 100 1
RS 232C-Schnittstelle für MODBUS I 1
PM 645A:
RS 232C für Advant Engineering-Station 100 1
RS 232C-Schnittstelle für MODBUS I 1
RS-422 (schnelle serielle Verbindungen) 2
Integrierte Mehrheitsbewertg. (Redundanz-Mgmt) 1
Gesamte E/A-Leistung
E/A-Kanäle 3 max. 1.500
E/A-Module max. 75
E/A-Stationen max. 7
Anzahl der Baugruppenträger pro E/A-Station max. 2
Anzahl der Modul-Steckplätze pro Baugr.träger 7 max. 10
Hardware-Optionen
Advant Fieldbus 100 redundant, Koaxialkabel,
zwei CI630 9 max. 1
Advant Fieldbus 100 (AF 100) redundant, Koaxialkabel,
eine CI630 10 max. 1
CI631 für untergeordneten, redundanten AF 100 und S800
E/A-Verbindung max. 1 redundantes Paar
Schnittstellenmodulträger SC610 2 max. 1
- RCOM/RCOM+Schnittstelle, CI532V01, 2 Kanäle 2 max.2
- MODBUS I-Schnittstelle, CI532V02, 2 Kanäle 2 max. 2
- Siemens 3964R, CI532V03, 2 Kanäle 2 max. 2
Analog Eingänge 8
0...20mA
- 32 Kanäle, einseitig, Auflösung 12 Bit (AI610)
- 16 Kanäle, als Gruppe potentialgetrennt, Auflösung
12 Bit, CMV=50V, CMRR >100 dB (AI625)
±10V/ ±20 mA
- 16 Kanäle, differentiell, Auflösung 12 Bit, CMV=100V,
CMRR >80 dB (bei 16,33, 50 oder 60 Hz) (AI620)
Pt100 oder Widerstand
- 12 Kanäle, -200...600?C oder 0...500?, 0,5 V, 3- oder
4 Leiter, als eine Gruppe potentialgetrennt, Auflösung
13 Bit, CMRR>100dB (AI630)
Thermoelemente
- 14 Mess- + 2 Referenzkanäle, Meßbereich C und J, als
eine Gruppe potentialgetrennt, Auflösung 12 Bit,
CMRR >120 dB (AI635)
Analog Ausgänge
0…20mA
- 16 Kanäle, als eine Gruppe potentialgetrennt,
Auflösung 12 Bit (AO610)
±10V/ ±20 mA, 4-20 mA, 0-5V, 0-10V, 1-5 V
- 8 Kanäle, einzeln potentialgetrennt, Auflösung 12 Bit
(AO650)
