GE DS3800NHVK1A1A Speedtronic Circuit Board, Advanced Turbine Control Module

GE DS3800NHVK1A1A Speedtronic Circuit Board, Advanced Turbine Control Module

Part Number:DS3800NHVK1A1A Brand:General Electric Application Category:Turbine Control Series:Mark IV DS3800 Product Type:LCI Drive, High Voltage Board Module Size:Standard Circuit Board Size Material:High-Quality Conductive Materials Operating Temperature Range:-20"C to +70"C Electrical Rating:High Voltage, High Current Input/Output Connections:Flexible and Durable Connectors Power Consumption:Optimized for Energy Efficiency The DS3800NHVK1A1A circuit board is engineered with precision and reliability, offering unparalleled performance in high-voltage drive systems.

It is meticulously designed to withstand the rigors of industrial use, ensuring long-lasting durability and efficiency. Featuring an advanced printed circuit board (PCB) structure, this component ensures seamless integration into existing systems, minimizing downtime and maximizing operational efficiency. Its robust design guarantees optimal power management and control, making it an indispensable part of modern industrial machinery. Our team of experts ensures that every DS3800NHVK1A1A board meets stringent quality standards, adhering to the highest industry benchmarks for reliability and safety.

This commitment to excellence translates into unparalleled peace of mind for our valued customers. Designed for compatibility with various industrial applications, the DS3800NHVK1A1A circuit board offers versatile functionality tailored to meet the specific needs of turbine control systems. Whether it  enhancing performance, improving efficiency, or ensuring safety, this board delivers exceptional results. For detailed specifications or to receive a quote, please contact AX Control today. Our knowledgeable staff is dedicated to providing personalized support, helping you find the right solution for your unique requirements. The GE DS3800NHVK1A1A is a critical component in high-voltage drive systems, designed for seamless integration into GE  Speedtronic turbine control systems, ensuring efficient operation and precise control in power generation applications.

Features

 Single-Slot Module

 SNP/SNP-X Protocol (master, slave)

 CCM Protocol (master, slave, peer)

 RTU Modbus Protocol (slave only)

 Supports connection to MS-DOS

 or Windows

 programming and configuration software package (monitor only)

 12 Mhz, 80C186 Microprocessor

 Two RS-422/RS-485 or RS-232 Serial Ports

 CCM, RTU and SNP/SNP-X Available on Either or Both Ports

 Simultaneous Communications on Both Ports (up to 9.6 Kbps, or 19.2 Kbps individually)

 High Performance Access to PLC Memory

 Three Status LEDs

 Reset pushbutton

 Soft Switch Configuration (no switches or jumpers)

 No Battery Required
