GE Intelligent Platforms Marine Industrial PC

GE  Intelligent Platforms Marine Industrial PC

DESCRIPTION

GE Intelligent Platforms has developed  a rugged, versatile, high-performance  Industrial PC specifically for demanding  marine applications.

Based on the RXi-XP IPC industrial  computing platform, the Marine  IPC delivers compact, rugged, high  performance computing capabilities. It  features a fanless design and extended  temperature range for reliable  operation in bridge, control room, and  machinery room applications. It has  been certified by DNV GL, the world’s  largest ship and offshore classification  society, to comply with marine-grade  standards for temperature, humidity,  vibration, and electromagnetic  compatibility (EMC).

DNV Certification

DNV Class A certification allows the Marine  IPC to be used in specified bridge, control  room, and machine room applications.  DNV certification is an industry-recognized  indicator of quality and safety, backed by  rigorous testing methods that ensure that  shipboard components perform under  extreme conditions.

High-Performance  Computing

The Marine IPC incorporates the latest  technologies to deliver high-performance  computing in marine environments. The Marine IPC has 4 GB of ECC RAM, 5  Gigabit Ethernet interfaces, and industrial  grade high-speed SSD storage to complete  the high-performance design. The Marine IPC provides additional  application flexibility with both mini PCI  Express and low profile PCI Express slots.

Rugged, Fanless Design for  Marine Environments

The Marine IPC combines high performance  with reliability. All aspects of the Marine  IPC have been engineered for reliability in  harsh shipboard conditions. The Marine  IPC features a fanless, solid state design  and is constructed from industrial-strength  components. The CPU and memory are  soldered to the board, boosting reliability  and resistance to shock and vibration.  Patented heat dissipation technology  allows the Marine IPC to perform in  extreme temperature conditions.

Modularity for Greater  Flexibility & Uptime

The Marine IPC features a rugged, COM  Express-based modular architecture  designed to extend the useful life of the  IPC and future-proof your system. The  COM Express module can be upgraded as  technology evolves. The wiring and housing  remain unchanged, lowering recertification  costs and reducing total cost of ownership.

FEATURE

·Dual core 2.5GHz Intel® i7,  Intel Celeron® 1.4GHz

·Fanless operation

·Extended temperature range

·0, 2, or 4 PCI Expansion slots

BENEFIT

• Delivers high performance computing for marine applications

• Robust and reliable, with no moving parts and minimized dust contamination

• Operating temperature range of up to 0°C to +60°C is possible

• Designed for high-temperature shipboard environments

• Add new functionality on demand to support specific application needs

Specifications

Processor

• Dual core 2.5GHz Intel i7

• Intel Celeron 1.4GHz

Non-Volatile Memory

• 512 kByte nv-SRAM (flat memory) – 2/4 slot version only

• Storage for process relevant data

2.5 inch SATA Interface

• 2.5" SATA Solid State Drive (SSD) – user accessible

• Usage of SSD for shock and vibration immunity as well  as extended temperature applications

• CFast Card Slot

• CFast slot with external access

• CFast card, bootable

• Operates in parallel with optional onboard HDD/SSD

Software Support

• Microsoft® Windows® 7 Professional 64-Bit

• Linux, Kernel 2.6.32

• VxWorks 6.9 with Intel Core i7 processor
