GE PACSystems™ RX7i IC698CPE030 Central Processing Unit

GE PACSystems™ RX7i IC698CPE030 Central Processing Unit

DESCRIPTION

The RX7i CPUs are programmed and configured by the programming software to perform real time  control of machines, processes, and material handling systems. The CPU communicates with I/O and  smart option modules over a rack-mounted backplane using the VME64 Standard format. It  communicates with the programmer and HMI devices via the embedded Ethernet ports or a serial port  using SNP Slave protocol.

CPE030:   600MHz Pentium-M microprocessor with 64 MB of user memory and 64 MB of user flash

CPE040:   1800MHz Pentium-M microprocessor with 64 MB of user memory and 64 MB of user flash

Features

■ Contains 64 Mbytes each of battery-backed user memory and non-volatile flash user memory for  user data (program, configuration, register data, and symbolic variable) storage.

■ Access to bulk memory via reference table %W.

■ Configurable data and program memory.

■ Programming in Ladder Diagram, C, Structured Text, and Function Block Diagram.

■ Auto-located Symbolic Variables that can use any amount of user memory.

■ Support for Series 90-70 discrete and analog I/O, communications, and other modules. For a list  of modules supported, refer to the PACSystems RX7i Installation Manual, GFK-2223.

■ Support for all non-GE Fanuc VME modules supported by Series 90-70.

■ PLC data monitoring over the web. Allows a combined total of up to 16 web server and FTP  connections.

■ Up to 512 program blocks. Maximum size for a block is 128KB.

■ Test Edit mode that allows you to easily test modifications to a running program.

■ Bit-in-word referencing

■ Battery-backed calendar clock.

CPU and module firmware upgrades via Winloader through CPU’s RS-232 or RS-485 serial port.

■ Three isolated serial ports: an RS-485 serial port, an RS-232 serial port, and an RS-232 Ethernet  station manager serial port.

■ An embedded Ethernet interface with:

− Data exchange using Ethernet Global Data (EGD)

− TCP/IP communication services using SRTP

− Modbus TCP server

− Full PLC programming and configuration services

− Comprehensive station management and diagnostic tools

− Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network  switch providing auto-negotiated network speed, duplex mode, and crossover detection.

Specifications

Time of Day Clock accuracy：Maximum drift of ±2 seconds per day

Elapsed Time Clock (internal timing) accuracy：±0.01% maximum

Embedded communications：RS-232, RS-485, Ethernet interface

Serial Protocols supported：Modbus RTU Slave, SNP, Serial I/O

Ethernet Ports：Embedded auto-sensing 10/100 Mbps half/full duplex Ethernet  interface

VME Compatibility：System designed to support the VME64 standard ANSI/VITA 1

Program blocks：Up to 512 program blocks. Maximum size for a block is 128KB.

Web-based data monitoring：Up to 16 web server and FTP connections (combined)

Ethernet data rate：10Mb/sec and 100Mb/sec

Physical interface：10BaseT RJ45

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
