Home >> GE >> GE IC200UAL004 Micro 23 PLCs
Current position：

Brand
GE IC200UAL004 Micro 23 PLCs
❤ Add to collection

GE IC200UAL004 Micro 23 PLCs

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

The Micro 23 PLC is big on features with 23 discrete I/O and two analog inputs and one

analog output built-in (expandable to 135 I/O) points. The Micro 23 executes fast cycle

times, robust instruction set, and generous memory to allow more flexible programming.

And it’s all packaged in a sturdy modular design for easy access and long-term durability.

￥11000.00
￥11000.00
Weight：3.550KG
Quantity：
(Inventory: 10)
Consultation
Accessories
  • Motorola V7768 D
    Original ：￥23885.00
    With a price ：￥23885    		 Quantity
  • KEBA CP505 The f
    Original ：￥2900.00
    With a price ：￥2900    		 Quantity
    •
    Original ：￥
    0.00

      With the total price ：￥
    0.00
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

The Micro 23 PLC is big on features with 23 discrete I/O and two analog inputs and one

analog output built-in (expandable to 135 I/O) points. The Micro 23 executes fast cycle

times, robust instruction set, and generous memory to allow more flexible programming.

And it’s all packaged in a sturdy modular design for easy access and long-term durability.



GE IC200UAL004 Micro 23 PLCs

Programmable Controllers
The Micro 23 PLC is big on features with 23 discrete I/O and two analog inputs and one
analog output built-in (expandable to 135 I/O) points. The Micro 23 executes fast cycle
times, robust instruction set, and generous memory to allow more flexible programming.
And it’s all packaged in a sturdy modular design for easy access and long-term durability.
Micro 23 PLCs
IC200UAL004 IC200UAL005 IC200UAL006
Product Name
23 point; (13) 12 VDC In,
(10) Relay Out,
(2) Analog In and (1) Analog Out,
12 VDC Powered.
23 point; (13) 24 VDC In,
(9) Relay Out, (1) 24 VDC Out,
(2) Analog In and (1) Analog Out, 24
VDC Powered.
23 point; (13) 24 VDC In,
(9) Relay Out, (1) 24 VDC Out,
(2) Analog In and (1) Analog Out,
120/240 VAC Powered.
Lifecycle Status Active Active Active
Number of Discrete Inputs/Outputs 13 In / 10 Out
(Supports 4 Expansion Units)
13 In / 10 Out
(Supports 4 Expansion Units)
13 In / 10 Out
(Supports 4 Expansion Units)
Number of Analog Inputs/Outputs
2 analog in / 1 analog out built-in and
supports up to 4 analog expansion
units (16 analog in/ 8 analog out)
2 analog in / 1 analog out built-in and
supports up to 4 analog expansion
units (16 analog in/ 8 analog out)
2 analog in / 1 analog out built-in and
supports up to 4 analog expansion
units (16 analog in/ 8 analog out)
Physical I/O Maximum 135 135 135
User Program Logic Memory (Words) 9 K 9 K 9 K
Registers (Words) 2 K 2 K 2 K
Analog Pots for Data Adjustment Yes, 2 Yes, 2 Yes, 2
Serial Port Connector Type RJ-45 (RS-232) port 1 and
DB-15 (RS-485 on port 2)
RJ-45 (RS-232) port 1 and
DB-15 (RS-485 on port 2)
RJ-45 (RS-232) port 1 and
DB-15 (RS-485 on port 2)
Protocols
Port 1, SNP, SNP X (Breakless);
Port 2, SNP, SNP X (Breakless),
RTU Master and Slave
(2 and 4 wire RTU Slave),
SNP Master, Serial Read
and Write
Port 1, SNP, SNP X (Breakless);
Port 2, SNP, SNP X (Breakless),
RTU Master and Slave
(2 and 4 wire RTU Slave),
SNP Master, Serial Read
and Write
Port 1, SNP, SNP X (Breakless);
Port 2, SNP, SNP X (Breakless),
RTU Master and Slave
(2 and 4 wire RTU Slave),
SNP Master, Serial Read
and Write
Power Voltage 12 VDC 24 VDC 120/240 VAC
Input Power Supply Rating 8 Watts 8 Watts 34 VA
24 VDC User Power for Sensors 200 mA 200 mA 200 mA
Input Device Voltage 12 VDC 24 VDC 24 VDC
Maximum Type A and B Counters 4 Type A and 1 Type B
@ 10Khz (16 bit)
4 Type A and 1 Type B
@ 10Khz (16 bit)
4 Type A and 1 Type B
@ 10Khz (16 bit)
Analog Input Ranges
0 to 10 VDC (10.24V max.) 0 to 20 mA
(20.5 mA max.) 4 to 20 mA (20.5 mA
max.); 12 bit Resolution
0 to 10 VDC (10.24V max.) 0 to 20 mA
(20.5 mA max.) 4 to 20 mA (20.5 mA
max.); 12 bit Resolution
0 to 10 VDC (10.24V max.) 0 to 20 mA
(20.5 mA max.) 4 to 20 mA (20.5 mA
max.); 12 bit Resolution
Output Control Voltage Relay Out Relay Out Relay Out
Relay Maximum Resistive
Load Rating
2 Amps at 24 VDC
and 240 VAC
2 Amps at 24 VDC
and 240 VAC
2 Amps at 24 VDC
and 240 VAC
Maximum Number of PWM/Pulse Outputs N/A 1 @ 5Khz (16 bit) 1 @ 5Khz (16 bit)
Analog Output Ranges
0 to 10 VDC (10.24V max.) 0 to 20 mA
(20.5 mA max.) 4 to 20 mA
(20.5 mA max.); 12 bit Resolution
0 to 10 VDC (10.24V max.) 0 to 20 mA
(20.5 mA max.) 4 to 20 mA
(20.5 mA max.); 12 bit Resolution
0 to 10 VDC (10.24V max.) 0 to 20 mA
(20.5 mA max.) 4 to 20 mA
(20.5 mA max.); 12 bit Resolution
Dimensions (WxHxD) mm 150x90x76 150x90x76 150x90x76
Programming Software
VersaPro 1.1 or greater,
Proficy Machine Edition
Logic Developer
VersaPro 1.1 or greater,
Proficy Machine Edition
Logic Developer
VersaPro 1.1 or greater,
Proficy Machine Edition
Logic Developer

Portable Memory Module Support No No No

VersaMax Nano and Micro Programmable Controllers

The Micro 28 PLC is big on features with the built-in 28 I/O (expandable to 140 I/O) points
to fast cycle times, two built-in serial ports, robust instruction set, and generous memory
to allow more flexible programming. And it’s all packaged in a sturdy modular design for
easy access and long-term durability. This all-in-one PLC gives you everything you need
to control a wide variety of applications.
Micro 28 PLC
IC200UAA007 IC200UAR028 IC200UDD110 IC200UDD120
Product Name
28 point; (16) 120 VAC In,
(12) 120 VAC Out,
120/240 VAC Powered.
28 point, (16) 120 VAC In,
(12) Relay Out,
120/240 VAC Powered.
28 point; (16) 24 VDC In,
(12) 24 VDC Out (6) @ 1.0 A, (6)
@ 0.5 A, 24 VDC Powered.
28 point; (16) 24 VDC In,
(12) 24 VDC Out (6) @ 1.0 A, (6)
@ 0.5 A, 24 VDC Powered.
Lifecycle Status Active Active Active Active
Number of Discrete Inputs/Outputs
16 In / 12 Out
(Supports 4 Expansion Units)
16 In / 12 Out
(Supports 4 Expansion Units)
16 In / 12 Out
(Supports 4 Expansion Units)
16 In / 12 Out
(Supports 4 Expansion Units)
Number of Analog Inputs/Outputs
Supports up to 4 analog
expansion units
(16 analog in/ 8 analog out)
Supports up to 4 analog
expansion units
(16 analog in/ 8 analog out)
Supports up to 4 analog
expansion units
(16 analog in/ 8 analog out)
Supports up to 4 analog
expansion units
(16 analog in/ 8 analog out)
Physical I/O Maximum 140 140 140 140
User Program Logic Memory (Words) 9 K 9 K 9 K 9 K
Registers (Words) 2 K 2 K 2 K 2 K
Analog Pots for Data Adjustment Yes, 2 Yes, 2 Yes, 2 Yes, 2
Serial Port Connector Type RJ-45 (RS-232) port 1 and
DB-15 (RS-485 on port 2)
RJ-45 (RS-232) port 1 and
DB-15 (RS-485 on port 2)
RJ-45 (RS-232) port 1 and
DB-15 (RS-485 on port 2)
RJ-45 (RS-232) port 1 and
DB-15 (RS-485 on port 2)
Protocols
Port 1, SNP, SNP X (Breakless);
Port 2, SNP, SNP X (Breakless),
RTU Master and Slave
(2 and 4 wire RTU Slave),
SNP Master, Serial Read
and Write
Port 1, SNP, SNP X (Breakless);
Port 2, SNP, SNP X (Breakless),
RTU Master and Slave
(2 and 4 wire RTU Slave),
SNP Master, Serial Read
and Write
Port 1, SNP, SNP X (Breakless);
Port 2, SNP, SNP X (Breakless),
RTU Master and Slave
(2 and 4 wire RTU Slave),
SNP Master, Serial Read
and Write
Port 1, SNP, SNP X (Breakless);
Port 2, SNP, SNP X (Breakless),
RTU Master and Slave
(2 and 4 wire RTU Slave),
SNP Master, Serial Read
and Write
Power Voltage 120/240 VAC 120/240 VAC 24 VDC 24 VDC
Input Power Supply Rating 16 VA 16 VA 5 Watts 5 Watts
24 VDC User Power for Sensors N/A 200 mA 200 mA 200 mA
Input Device Voltage 120 VAC 120 VAC 24 VDC 24 VDC
Maximum Type A and B Counters N/A N/A 4 Type A and 1 Type B
@ 10Khz (16 bit)
4 Type A and 1 Type B
@ 10Khz (16 bit)
Output Control Voltage 120 VAC Relay Out 24 VDC 24 VDC ESCP, Self Healing,
No External Fusing Required
Relay Maximum Resistive
Load Rating
N/A 10 @ 2 Amps at 24 VDC and
240 VAC; 2 @ 10 Amps at
24 VDC and 240 VAC
N/A N/A
Maximum Number of
PWM/Pulse Outputs N/A N/A 4 @ 5Khz (16 bit) 4 @ 5Khz (16 bit)
Dimensions (WxHxD) mm 150x90x76 150x90x76 150x90x76 150x90x76
Programming Software
VersaPro 1.1 or greater,
Proficy Machine Edition
Logic Developer
VersaPro 1.1 or greater,
Proficy Machine Edition
Logic Developer
VersaPro 1.1 or greater,
Proficy Machine Edition
Logic Developer
VersaPro 1.1 or greater,
Proficy Machine Edition
Logic Developer
Portable Memory Module Support No No No No
  • ADLINK NuPRO-E72 PICMG 1.3 Full length Industrial SHB Single Board Computer
  • ADLINK MXE-5400 series fanless embedded industrial computer
  • ADLINK M-322 Industrial ATX Motherboard
  • ADLINK IMB-M43H Industrial ATX Motherboard
  • ADLINK IMB-M42H Industrial ATX Motherboard
  • ADLINK i915GV-INA ATX motherboard
  • ADLINK ETX-NR667 Embedded ETX Standard Computer Module
  • ADLINK ETX-BT (PATA to SATA version) User Manual
  • ADLINK CM1-BT1 PC/104 Single Board Computer
  • ADLINK cPCI-8217 [R] 3U CompactPCI VGA/LCD Display Module
  • ADLINK AmITX-SL-G Mini ITX Embedded Motherboard
  • ADLINK AmITX-AL-I ultra-thin Mini ITX industrial motherboard
  • ADLINK NuPRO-E315 Full length PICMG 1.3 Industrial SHB Single Board Computer
  • ADLINK NuPRO-842 Full length PICMG 1.0 PCI/ISA Industrial Single Board Computer
  • ADLINK NuPRO-900A PICMG 1.2 ePCI-X Dual Xeon Industrial System Motherboard (SHB)
  • ADLINK cPCI-6910 series 6U CompactPCI single board computer
  • ADLINK cPCI-6860A 6U CompactPCI dual core single board computer with cPCI-R6860A rear adapter board
  • ADLINK cPCI-8168 6U CompactPCI Eight Axis Motion Control Card
  • ADLINK NuPRO-E340 PICMG 1.3 Industrial SHB motherboard
  • ADLINK NuPRO-A40H Full length PICMG1.0 Industrial Single Board Computer (SBC)
  • ADLINK NuPRO-852 Full length PICMG1.0 Industrial Single Board Computer
  • ADLINK NuPRO-841 Full length Industrial SBC
  • ADLINK NuPRO-590/591/592 series Socket7 full-length industrial SBC
  • ADLINK MXE-5500 series fanless embedded industrial computer
  • ADLINK MXE-200/200i Fanless Embedded Machine
  • ADLINK cPCI-6770 series CompactPCI CPU board
  • ADLINK NuPRO-A301 standard PICMG 1.0 full-length industrial SBC single board computer
  • ADLINK NuPRO-965 PICMG 1.3 SHB Express Full length Industrial Motherboard
  • ADLINK NuPRO-935A Full length PICMG1.0 Industrial Single Board Computer
  • ADLINK NuPRO-865 Full length Single Board Computer
  • ADLINK NuPRO-840 DV/LV Full Length PICMG Industrial Single Board Computer
  • ADLINK NuPRO-770 series full-length industrial single board computer
  • ADLINK NuPRO-595 series half length Socket 7 industrial motherboard
  • ADLINK cPCI-6840 series 6U CompactPCI single board computer
  • Foxboro 43AP series pneumatic indicator controller (PSS 3-1B3 A)
  • ADLINK cPCI-3720 Series 3U Low Power CompactPCI Single Board Computer
  • ADLINK NuPRO-E47, PICMG 1.3 full-length industrial SHB system motherboard
  • ADLINK NuPRO-E43 PICMG 1.3 full-length system motherboard
  • ADLINK NuPRO-780 series full-length industrial CPU board
  • ADLINK cPCI-6965 series 6U CPCI single board computer
  • ADLINK USB/LPCI/LPCIe-3488A GPIB interface card
  • Rittal SK 3241.700 Blue e+Fan Filter Unit
  • ADLINK cPCI-8168 6U CompactPCI 8-Axis Motion Control Card
  • ADLINK PCIe PXIe-8638 PCIe to PXIe Bus Expansion Kit
  • ADLINK PCIe GIE7x series acquisition card
  • ADLINK PCIe-7396 96 96 channel TTL digital IO card
  • ADLINK PCI/MPC/PXI-8164 Three in One Motion Control Card
  • ADLINK PCI-8154 Four Axis Pulse Motion Control Card
  • ADLINK PCI-8134 Four Axis Servo/Stepper Motion Control Card
  • ADLINK NuPRO-E42 PICMG1.3 full-length SHB motherboard
  • ADLINK MXC-6600 series high-performance fanless extended industrial computer
  • ADLINK MXC-6000 series embedded industrial control computer
  • ADLINK MXC-2300 series fanless expandable embedded industrial computer
  • ADLINK MCM-204 Independent Ethernet DAQ User Manual
  • ADLINK MCM-100/102 Edge IoT Platform for Machine Condition Monitoring User’s Manual
  • ADLINK MXC-6400 series sixth generation Core Fanless Scalable Industrial Control Computer
  • ADLINK Matrix Full Series Fanless Embedded Industrial Control Computers
  • ADLINK GIE64+4-channel PoE Gigabit Vision Capture Card
  • Honeywell UMS Security System Troubleshooting Guide
  • Honeywell Expert Series-C I/O Module
  • ADLINK EOS-1200 Embedded Vision Host
  • ADLINK DLAP-5200 series high-performance fanless AI industrial computer
  • ADLINK DLAP-4000 series embedded industrial control computer
  • ADLINK Matrix MXC-2000 Series Fanless Industrial Control Computer Specification
  • ADLINK DAQ -/DAQE -/PXI-2000 Series Multi functional Synchronous Acquisition Card
  • ADLINK cPCI-6520 6U CompactPCI Single Board Computer
  • ADLINK CM1-86DX3 PC/104 Single Board Computer
  • Honeywell DC1000 series PID temperature controller
  • ALSTOM MiCOM C264 Modular Substation Controller
  • EMERSON AMS 2140 Mechanical Health Analyzer
  • ADLINK NuPRO-E320 PICMG1.3 Full length Industrial Motherboard
  • ADLINK NuPRO-800 Series Full length Industrial SBC User Manual
  • ADLINK NuPRO-598 Industrial Single Board Computer
  • ADLINK MXC-6300 Fanless Embedded Industrial Control Computer
  • ADLINK Express-BASE7 User Manual
  • ADLINK DLAP-211 Series Fanless Edge AI Platform Specification Manual
  • ADLINK PCI/LPCI/LPCIe/cPCI-723X series 32 channel isolated digital I/O card
  • ADLINK cPCI-6965 series 6U CompactPCI single board computer
  • ADLINK NuDAQ 7200 series high-speed digital I/O board
  • Linghua ADLINK DLAP Deep Learning Acceleration Platform Product Manual
  • DEIF TCM-2 thyristor control module
  • Installation Manual for DEIF MVR-200 Series Medium Voltage Protection Device
  • DEIF MDR-2 multifunctional differential relay
  • DEIF AOM-1 Analog Output Module
  • DEIF AGI 400 series industrial/marine touch screen
  • Installation Manual for DEIF BRW-1 Marine Wing Bridge Instrument
  • DEIF AGC200 Quick Start Guide
  • DEIF AGC Multi line 2 Generator Set ControllerProduct basic information
  • ABB SPA-ZC 400 Ethernet Gateway Installation and Debugging Manual
  • ABB REM 543/545 motor generator protection device
  • DEIF PPU 300 controller
  • DEIF Delomatic 4 Offshore/Ocean Platform Dedicated Generator Power Management System DM-4
  • DEIF Delomatic Modular Generator Set Integrated System
  • DEIF AGC-4 Mk II Generator Set Controller
  • DEIF AGC-4 diesel generator set integrated controller
  • DEIF Multi line 2 Series PPU Unit Power Management (PPM) Operation Manual
  • DEIF Multi line 2 V2.4X Installation Manual
  • Beckwith M-6280 Digital Capacitor Bank Controller
  • Beckwith M-3311 Transformer Protection Relay
  • Beckwith M-3311A Transformer Integrated Protection Device
  • Beckwith M-3310 Transformer Integrated Protection Device Specification
  • Beckwith M-0359 Syncrocloser Check Plus Application Guide for Synchronous Calibration Relay
  • Beckwith M-0293A On Load Tap changer Controller Application Guide
  • DEIF GPU-3 Synchronous/Asynchronous Generator Integrated Microcomputer Protection Controller
  • Installation Instructions for DEIF PPM-3
  • Beckwith M-3520 distributed power grid connected comprehensive protection device
  • Beckwith M-3430 generator comprehensive protection device
  • Beckwith M-2293B adapter panel
  • Beckwith M-2001C digital on load voltage regulator controller
  • Beckwith M-2001B Digital On Load Voltage Regulating Controller
  • Beckwith M-0388/M-0389 synchronous verification relay
  • Beckwith M-0193B synchronous closing device
  • Beckwith M-0115A Transformer Parallel Balancing Module
  • Beckwith M-0067E on load tap changer controller
  • Beckwith M-4272 Digital Motor Bus Switching System
  • Beckwith M-3311A Transformer Integrated Protection Device
  • Beckwith M-3425A Generator Integrated Protection Device Manual
  • Basler BE1-27/BE1-59/BE1-27/59 undervoltage/overvoltage relay
  • Basler AVC63-12/AVC125-10 excitation voltage regulator
  • Basler L301kc Color Three Line Array Camera Operation Manual
  • Basler CBS 212A Current Enhanced Excitation System
  • Basler BE3-25 synchronous check relay
  • Operation Manual for Basler BE1-32R/BE1-32O/U Direction Power Relay
  • Basler Electric PRS-250 Veri Sync Synchronous Relay
  • Basler Pilot Series Area Array Industrial Camera piA2400-17gc
  • Basler BE1-11g comprehensive protection device for generator
  • Basler VR63-4C/UL Analog Excitation Voltage Regulator
  • Basler BE1-DFPR distribution feeder protection relay
