GE IC694MDL742 Output Module High Performance Control Solution

GE IC694MDL742 Output Module  High Performance Control Solution

Model Type:Digital I/O Module Product ID:IC694MDL742 Manufacturer:GE Output Channel Count:16 Module Circuit Type:Sourcing Voltage Range (DC):12 to 24 volts Input Voltage (DC):5 Volts Operating Voltage (DC):+5 VDC, +12 VDC Network Ports:N/A LEDs:4 Dimensions:W 13 cm, H 2.7 cm, D 29.2 cm Weight:0.32 kg Certification:Certified Series:Mark VI Compatible Systems:GE PLC series This advanced digital output module from GE is engineered for seamless integration into complex industrial control systems.

Its robust design ensures stable performance under demanding conditions, making it a preferred choice for manufacturing, process control, and automation projects. Featuring positive logic output, this module guarantees accurate signal transmission without the need for additional circuitry. It supports a wide range of output voltages, providing flexibility across various industrial applications. Crafted with precision and reliability at its core, the GE IC694MDL742 Digital Output Module comes equipped with critical components designed to withstand harsh environments, ensuring longevity and maintenance-free operation.

 Installation and configuration are straightforward, thanks to its user-friendly interface and comprehensive documentation provided by GE. This makes it accessible to both experienced engineers and those new to industrial automation. With a commitment to quality and innovation, GE  IC694MDL742 Digital Output Module offers unparalleled performance and reliability. Backed by extensive testing and industry-leading support, this module is the perfect addition to any system requiring precise and dependable digital control. The GE IC694MDL742 Output Module is a high-performance control solution designed for industrial automation systems, offering precise digital output control for various applications.

Features

 Single-Slot Module

 SNP/SNP-X Protocol (master, slave)

 CCM Protocol (master, slave, peer)

 RTU Modbus Protocol (slave only)

 Supports connection to MS-DOS or Windows

 programming and configuration software package (monitor only)

 12 Mhz, 80C186 Microprocessor

 Two RS-422/RS-485 or RS-232 Serial Ports

 CCM, RTU and SNP/SNP-X Available on Either or Both Ports

 Simultaneous Communications on Both Ports (up to 9.6 Kbps, or 19.2 Kbps individually)

 High Performance Access to PLC Memory

 Three Status LEDs

 Reset pushbutton

 Soft Switch Configuration (no switches or jumpers)

 No Battery Required

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
