GE IC697CGR772 One Slot Controller for Efficient Industrial Automation
Product Type:Single Slot Controller Model Number:IC697CGR772 Module Designation:PLC Dimensions:4.2 x 10 x 22 cm Weight:0.5 kg Processor:Intel 80486DX4 Clock Speed:96 MHz RAM:512 KB Communication Ports:1 RS232, 2 RS485 interfaces Power Input:5V DC Analog Inputs:8 channels Analog Outputs:N/A Digital Inputs:N/A Digital Outputs:N/A Operating Temperature:-10"C to 55"C Storage Temperature:-40"C to 70"C The GE IC697CGR772 One Slot Controller is an indispensable component for enhancing the operational efficiency of industrial automation systems.
Designed with cutting-edge technology, it ensures reliable performance across a wide range of industrial applications. With its compact size and versatile connectivity options, including RS-485 and DeviceNet interfaces, this controller seamlessly integrates with existing systems, facilitating easy installation and configuration. Featuring eight digital inputs and four digital outputs, it provides flexible control over various processes, enabling precise monitoring and control of industrial operations.
Its 12VDC power supply ensures robust performance under demanding conditions. Engineered for optimal performance within the temperature range of -20"C to +70"C, this controller operates reliably in various industrial environments. The IP20 enclosure protects against dust and light splashes, ensuring durability and longevity. Weighing just 0.3kg, the GE IC697CGR772 is lightweight yet sturdy, making it suitable for both new installations and retrofit scenarios. Its compatibility with diverse automation protocols enhances its adaptability and scalability within complex industrial setups. The GE IC697CGR772 is a cutting-edge one-slot controller designed for advanced industrial control applications, offering unparalleled reliability and efficiency.
Features
Complete Analog subsystem includes Base Converter and Expander modules
Base Converter module has eight differential inputs individually configurable for voltage or current
Accepts unipolar or bipolar Analog Inputs up to " 10 volts full scale
Accepts 4 to 20 milliamp current loop signals
Individual user scaling on each input channel on Base Converter module; scaling on a per module basis for Expander modules
Fast update rate for Base Converter module
Voltage and current Expander modules, each with 16 inputs, provides for additional inputs at a lower cost per point
Complete subsystem can accept up to 120 inputs
No jumpers or DIP switches to configure
Easy configuration with MS-DOS
or Windows
programming software configuration function.
Features
Single-Slot Module
SNP/SNP-X Protocol (master, slave)
CCM Protocol (master, slave, peer)
RTU Modbus Protocol (slave only)
Supports connection to MS-DOS or Windows
programming and configuration software package (monitor only)
12 Mhz, 80C186 Microprocessor
Two RS-422/RS-485 or RS-232 Serial Ports
CCM, RTU and SNP/SNP-X Available on Either or Both Ports
Simultaneous Communications on Both Ports (up to 9.6 Kbps, or 19.2 Kbps individually)
High Performance Access to PLC Memory
Three Status LEDs
Reset pushbutton
Soft Switch Configuration (no switches or jumpers)
No Battery Required
