GE IS200DSFCG1ADB Advanced Feedback Board for Industrial Control Systems
Model Number:IS200DSFCG1ADB Module Category:Feedback Board Functionality:Gate Driver and Shunt Feedback Compatible Applications:Steam and Gas Turbine Control Systems Dimensions (mm):178 x 114 x 25 Weight (g):200 Operating Voltage (V):DC 24 Current Capacity (A):1000/1800 The GE IS200DSFCG1ADB is a critical component in ensuring the optimal operation of steam and gas turbines through its advanced feedback mechanism. This board is meticulously designed to enhance system stability and efficiency by precisely controlling the flow of electrical signals to the turbine drives. Crafted from high-grade materials to withstand the rigors of industrial environments, the IS200DSFCG1ADB boasts exceptional durability and reliability.
Its compatibility with PWM bridges and AC drives ensures seamless integration into existing systems, maximizing operational flexibility and performance. Equipped with cutting-edge technology, this feedback board offers superior precision in managing electrical currents, making it indispensable for achieving precise control over turbine operations. Its compatibility with GE proprietary software for online maintenance further enhances system monitoring and troubleshooting capabilities, enabling efficient problem resolution and minimizing downtime. Operating within a wide temperature range of -10"C to 55"C, the IS200DSFCG1ADB ensures reliable performance across diverse geographical locations and environmental conditions.
With UL, CE, and ISO 9001 certifications, users can trust in the board compliance with international safety and quality standards. For those seeking unparalleled reliability, efficiency, and compatibility in their steam and gas turbine control systems, the GE IS200DSFCG1ADB is the premier choice. Contact our sales team today to discover how this innovative feedback board can elevate your operations. The GE IS200DSFCG1ADB is a sophisticated feedback board designed for enhanced performance in industrial control systems, specifically engineered for seamless integration into steam and gas turbine operations.
Compatibility
ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.
ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.
ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).
ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.
ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.
Module features include:
ƒ Support for all standard data rates (125K, 250K, 500K)
ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave
ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master
ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS
ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging
ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device
ƒ Support for configuration of the global scan rate
ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis
ƒ Support for PLC-application initiated explicit messaging via a COMMREQ
ƒ Master can be configured to operate as a slave simultaneously with master operation
ƒ Configurable fault behavior on loss of communication
ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)
ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)
ƒ Firmware update via service port on module
