Functional Characteristics

Signal acquisition and processing: It can acquire many types of industrial signals, such as analogue signals (e.g. temperature, pressure, flow and other sensor signals) and digital signals (e.g. switch status, limit signals, etc.). It can filter, amplify, convert and other processing of the collected signals to improve the quality and accuracy of the signals to meet the needs of the control system.

Control function: with powerful control capability, it can accurately control the equipments in the industrial site according to the preset control strategy and algorithm. The output control signals can drive various actuators, such as motors, valves, pumps, etc., to achieve automatic control of the production process.

Communication function: It supports various communication protocols, such as Profibus, Modbus, HART, etc., and can carry out efficient data communication and interaction with other devices. Through the communication interface, it can be connected with PLC, human-machine interface, upper computer monitoring system and other devices to achieve system integration and cooperative work, and facilitate remote monitoring and operation.

Technical Parameters

Power supply voltage: the general working voltage range between DC20V and DC30V, some special application scenarios may be different models, with a certain adaptability to voltage fluctuations, usually allow voltage fluctuations in the range of ±10% or so.

Number of input/output points: Usually there are multiple digital input/output points and analogue input/output points, the number of digital input/output points generally ranges from 8 to 32, and the number of analogue input/output points generally ranges from 4 to 8, which can be selected according to the specific model and application requirements.

Input and output signal type: digital input signal is usually DC24V level signal, digital output signal can be relay output, transistor output or thyristor output, etc., which can drive different types of loads. Analogue input signal is usually 0mA to 20mA, 4mA to 20mA current signal or 0V to 10V, -10V to +10V voltage signal, analogue output signal is usually 0mA to 20mA, 4mA to 20mA current signal or 0V to 10V voltage signal.

Communication interface: usually equipped with standard communication interface, such as RS485, RS232, Ethernet interface, etc., the communication rate varies according to different communication protocols and application requirements, such as Profibus communication rate of up to 12Mbps, Modbus communication rate of up to 115200bps and so on.

Application Scenario

Chemical industry: In the process of chemical production, it is used to monitor and control the temperature, pressure, liquid level and other parameters of the reaction kettle, as well as to control the flow rate of all kinds of chemical fluids and the opening of valves, so as to ensure the safety and stability of chemical production.

Power industry: in power plants and substations, it can be used to monitor and control the operation status of generator sets, voltage and current of power grids and other parameters, as well as to control the operation of circuit breakers, isolation switches and other power equipment, to ensure the reliable power supply of the power system.

Metallurgical industry: In the metallurgical production process of iron and steel, non-ferrous metals, etc., it is used to control the temperature of the heating furnace, the speed and pressure of the rolling equipment and other parameters, as well as to monitor and control the flow and composition of the fluids in various metallurgical processes, so as to improve the quality of the metallurgical products and the production efficiency.

Pharmaceutical industry: In the process of drug production, it is used to monitor and control the temperature, stirring speed, pH value and other parameters of the reaction tank, as well as to control the operation of various pharmaceutical equipment and material delivery, to ensure the quality and safety of drug production.

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
