Home >> GE >> GE IC693CPU363 CPUs module
Current position：

Brand
GE IC693CPU363 CPUs module
❤ Add to collection

GE IC693CPU363 CPUs module

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

For entry-level applications with low I/O counts, the CPU is embedded into the backplane, making all

slots available for I/O. These modules are compatible with advanced modules such as Ethernet, various

bus modules, and control. Mid-range CPU models are modular and come in various memory sizes,

performance capability and increased functionality such as overrides, battery-backed clock and

Programmable Coprocessor module support. The high-performance CPUs are based on the latest

386EX processor for fast computation and high throughput. They can handle up to 4,096 I/O and

start at 32K of memory and are programmable in a number of standard languages.

￥12888.00
￥12888.00
Weight：3.550KG
Quantity：
(Inventory: 20)
Consultation
Accessories
  • Motorola V7768 D
    Original ：￥23885.00
    With a price ：￥23885    		 Quantity
  • KEBA CP505 The f
    Original ：￥2900.00
    With a price ：￥2900    		 Quantity
    •
    Original ：￥
    0.00

      With the total price ：￥
    0.00
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

For entry-level applications with low I/O counts, the CPU is embedded into the backplane, making all

slots available for I/O. These modules are compatible with advanced modules such as Ethernet, various

bus modules, and control. Mid-range CPU models are modular and come in various memory sizes,

performance capability and increased functionality such as overrides, battery-backed clock and

Programmable Coprocessor module support. The high-performance CPUs are based on the latest

386EX processor for fast computation and high throughput. They can handle up to 4,096 I/O and

start at 32K of memory and are programmable in a number of standard languages.



GE IC693CPU363 CPUs module

Series 90-30 Programmable Controllers
CPUs
For entry-level applications with low I/O counts, the CPU is embedded into the backplane, making all
slots available for I/O. These modules are compatible with advanced modules such as Ethernet, various
bus modules, and control. Mid-range CPU models are modular and come in various memory sizes,
performance capability and increased functionality such as overrides, battery-backed clock and
Programmable Coprocessor module support. The high-performance CPUs are based on the latest
386EX processor for fast computation and high throughput. They can handle up to 4,096 I/O and
start at 32K of memory and are programmable in a number of standard languages.
IC693CPU363 IC693CPU366 IC693CPU367
Product Name CPU (Model 363) CPU (Model 366 with
built-in Profibus Master)
CPU (Model 367 with
built-in Profibus Slave)
Lifecycle Status Active Active Mature
Module Type
CPU Module CPU Module CPU Module
Boolean Execution Speed (ms/K) 0.22 0.22 0.22
User Logic Memory (K bytes) 240 240 240
Real Time Clock Yes Yes Yes
I/O Discrete Points 4096 4096 4096
I/O Analog Points 2048 In / 512 Out 2048 In / 512 Out 2048 In / 512 Out
Type of Memory Storage RAM, Flash RAM, Flash RAM, Flash
Processor Speed (MHz) N/A N/A N/A
Built-in Communication Ports
Three total. One RS-485 port on power
supply, one RS-232 and one RS-485 port
on CPU. Supports SNP, RTU Master and
Slave, Serial Read and Write
One Profibus DP Slave port and RS-485
port on power supply. Supports SNP.
One Profibus DP Master, Class 1 V0 port
and RS-485 port on power supply.
Supports SNP.
Total Number of Racks 8 8 8
Communications Option Modules
Serial-SNP, SNPX, RTU and CCM,
LAN-Genius, Ethernet SRTP and
Ethernet Modbus TCP
Serial-SNP, SNPX, RTU and CCM,
LAN-Genius, Ethernet SRTP and
Ethernet Modbus TCP
Serial-SNP, SNPX, RTU and CCM,
LAN-Genius, Ethernet SRTP and
Ethernet Modbus TCP
Field Busses/Device Networks
Ethernet, Genius, Profibus-DP, DeviceNet,
Interbus-S, CsCAN
Ethernet, Genius, Profibus-DP, DeviceNet,
Interbus-S, CsCAN
Ethernet, Genius, Profibus-DP, DeviceNet,
Interbus-S, CsCAN
Software Programming Support
Logicmaster (DOS),
VersaPro (Windows), Proficy Logic
Developer - Machine Edition
Proficy Logic Developer
- Machine Edition
Proficy Logic Developer
-Machine Edition
Internal Power Used 890 mA @ 5 VDC 940 mA @ 5 VDC 940 mA @ 5 VDC


Programmable Controllers
CPUs
For entry-level applications with low I/O counts, the CPU is embedded into the backplane, making all
slots available for I/O. These modules are compatible with advanced modules such as Ethernet, various
bus modules, and control. Mid-range CPU models are modular and come in various memory sizes,
performance capability and increased functionality such as overrides, battery-backed clock and
Programmable Coprocessor module support. The high-performance CPUs are based on the latest
386EX processor for fast computation and high throughput. They can handle up to 4,096 I/O and
start at 32K of memory and are programmable in a number of standard languages.
IC693CPU370 IC693CPU372 IC693CPU374 PLUS
Product Name
CPU (Model 370).
Requires High Capacity
Power Supply
CPU (Model 372 with
built-in 10/100 Mbps
Ethernet and WEB Enabled).
Requires High Capacity
Power Supply
CPU (Model 374 PLUS with
built-in 10/100 Mbps
Ethernet and Web Enabled).
Requires High Capacity
Power Supply
Lifecycle Status Active Active Active
Module Type CPU Module CPU Module CPU Module
Boolean Execution Speed (ms/K) 0.15 0.15 0.15
User Logic Memory (K bytes) 240 120 240
Real Time Clock Yes Yes Yes
I/O Discrete Points 4096 4096 4096
I/O Analog Points 2048 In / 512 Out 2048 In / 512 Out 2048 In / 512 Out
Type of Memory Storage RAM, Flash RAM, Flash RAM, Flash
Processor Speed (MHz) 133Mhz 133Mhz 133Mhz
Built-in Communication Ports
One RS-485 port
on power supply.
Supports SNP
One RS-485 port
on power supply.
Supports SNP and two
Ethernet ports;
(one IP address) on CPU,
10/100 Mbps built-in switch,
SRTP - channels
(Producer and Consumer);
EGD, Modbus TCP Client/Server
and Web Diagnostics Support
One RS-485 port
on power supply.
Supports SNP and two
Ethernet ports;
(one IP address) on CPU,
10/100 Mbps built-in switch,
SRTP - channels
(Producer and Consumer);
EGD, Modbus TCP Client/Server
and Web Diagnostics Support
Total Number of Racks 8 8 8
Communications Option Modules
Serial-SNP, SNPX, RTU and CCM,
LAN-Genius, Ethernet SRTP and
Ethernet Modbus TCP Client/Server
Serial-SNP, SNPX, RTU and CCM,
LAN-Genius, Ethernet SRTP and
Ethernet Modbus TCP Client/Server
Serial-SNP, SNPX, RTU and CCM,
LAN-Genius, Ethernet SRTP and
Ethernet Modbus TCP Client/Server
Field Busses/Device Networks Ethernet, Genius, Profibus-DP,
DeviceNet, Interbus-S, CsCAN
Ethernet, Genius, Profibus-DP,
DeviceNet, Interbus-S, CsCAN
Ethernet, Genius, Profibus-DP,
DeviceNet, Interbus-S, CsCAN
Software Programming Support Proficy Logic Developer
- Machine Edition
Proficy Logic Developer
- Machine Edition
Proficy Logic Developer
-Machine Edition
Internal Power Used 1.4 Amps @ 5 VDC 1.4 Amps @ 5 VDC 1.4 Amps @ 5 VDC
