ABB 1MRK 504 053-BEN Transformer protection
❤ Add to collection

ABB 1MRK 504 053-BEN Transformer protection

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

ABB 1MRK 504 053-BEN Transformer protection

28756.00
¥28740.00
Weight:3.600KG
Quantity:
(Inventory: 31)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

ABB 1MRK 504 053-BEN Transformer protection


ABB 1MRK 504 053-BEN Transformer protection

Features

• A protection, control, and monitoring IED with  extensive functional library and configuration  possibilities and expandable hardware design to  meet specific user requirements

• For power transformers, autotransformers, shunt  reactors, T-protection, generator transformer  blocks, phase shifting transformers and small  busbar systems

• For two- and three-winding transformers with up  to six stabilized inputs • For multi- or single-breaker arrangements

• Transformer differential protection with:

- Percentage bias restraint for through faults

- Waveform and Second harmonic restraint for  transformer inrush

- Fifth harmonic restraint for overexcitation

- High sensitivity for interturn faults

• Restricted earth fault protection for all direct or  low impedance earthed windings

- Extremely fast operation

- High sensitivity

- High and low impedance based

• Full scheme phase-to-phase and phase-to-earth  distance protection with up to five zones:

- Load encroachment feature

• Instantaneous high speed short circuit function  with low transient overreach

• Directional overcurrent protection with four steps  for each winding

- Each step can be inverse or definite time  delayed

- Each step can be directional or non-directional

• Instantaneous high speed earth fault function  with low transient overreach

• Directional earth fault protection with four stages  for each winding

- Each step can be inverse or definite time  delayed

- Each step can be directional or non-directional

- Each step can be blocked on second harmonic component

• Synchrocheck function for single- or  multi-breaker arrangements:

- Selectable energizing direction

- Two functions with built-in voltage selection

• Selectable additional software functions such as  breaker failure protection for each breaker, voltage protection, overexcitation protection, control  and monitoring

• Tripping from Buchholtz, temperature devices  etc. through binary inputs stabilized against  capacitive discharges

• Built-in data communication modules for station  bus IEC 61850-8-1

• Data communication modules for station bus  IEC 60870-5-103, LON and SPA

• Integrated disturbance and event recorder for up  to 40 analog and 96 binary signals

• Time synchronization over IEC 61850-8-1, LON,  SPA, binary input or with optional GPS module

• Analog measurements accuracy up to below  0.5% for power and 0.25% for current and voltage and with site calibration to optimize total  accuracy

• Versatile local human-machine interface

• Extensive self-supervision with internal event  recorder

• Six independent groups of complete setting  parameters with password protection

• Powerful software PC tool for setting, disturbance evaluation and configuration

• Remote end data communication modules for  C37.94 and G.703

Functions

• Differential protection

- Transformer differential protection, two winding (PDIF, 87T)

- Transformer differential protection, three  winding (PDIF, 87T)

- Restricted earth fault protection (PDIF, 87N)

- High impedance differential protection  (PDIF, 87X)

• Distance protection

- Distance protection zones (PDIS, 21)

- Phase selection with load encroachment  (PDIS, 21)

- Power swing detection (RPSB, 78)

- Automatic switch onto fault logic (PSOF)

• Current protection

- Instantaneous phase overcurrent protection  (PIOC, 50)

- Four step phase overcurrent protection  (POCM, 51/67)

- Instantaneous residual overcurrent protection  (PIOC, 50N)

- Four step residual overcurrent protection  (PEFM, 51N/67N)

- Thermal overload protection, two time constants (PTTR, 49)

- Breaker failure protection (RBRF, 50BF)

- Pole discordance protection (RPLD, 52PD)

• Voltage protection

- Two step undervoltage protection  (PUVM, 27)

- Two step overvoltage protection (POVM, 59)

- Two step residual overvoltage protection  (POVM, 59N)

- Overexcitation protection (PVPH, 24)

• Frequency protection

- Underfrequency protection (PTUF, 81)

- Overfrequency protection (PTOF, 81)

- Rate-of-change frequency protection  (PFRC, 81)

• Multipurpose protection

- General current and voltage protection  (GAPC)

• Secondary system supervision

- Current circuit supervision (RDIF)

- Fuse failure supervision (RFUF)

• Control - Synchrocheck and energizing check  (RSYN, 25)

- Apparatus control for single bay, max 8 app.  (1CB) incl. Interlocking (APC8)

- Apparatus control for single bay, max 15 app.  (2CBs) incl. Interlocking (APC15) -

 Apparatus control for up to 6 bays, max 30  app. (6CBs) incl. Interlocking (APC30)
